Standard fuses and circuit breakers

109908_en_02 Phoenix Contact 47 / 150

7 Standard fuses and circuit breakers

7.1 Standard fuses (for IEC)

The standard fuses (for IEC) have been tested in accordance with IEC/EN 61800-5-1.

Table 7-1 Protection with standard fuses (IEC)

CONTACTRON Speed Starter Fuse type (IEC)

Grid Model Power [kW] SCCR [kA] Fuse type Max. rated current [A]

1

1-phase CSS 0.25-1/3 0.25 30 gG 16

CSS 0.37-1/3 0.37 30 gG 16

CSS 0.55-1/3 0.55 30 gG 16

CSS 0.75-1/3 0.75 30 gG 16

CSS 1.5-1/3 1.5 30 gG 32

CSS 0.25-1/3-EMC 0.25 30 gG 16

CSS 0.37-1/3-EMC 0.37 30 gG 16

CSS 0.55-1/3-EMC 0.55 30 gG 16

CSS 0.75-1/3-EMC 0.75 30 gG 16

CSS 1.5-1/3-EMC 1.5 30 gG 32

3-phase CSS 0.25-3/3 0.25 30 gG 16

CSS 0.37-3/3 0.37 30 gG 16

CSS 0.55-3/3 0.55 30 gG 16

CSS 0.75-3/3 0.75 30 gG 16

CSS 1.5-3/3 1.5 30 gG 16

CSS 0.25-3/3-EMC 0.25 30 gG 16

CSS 0.37-3/3-EMC 0.37 30 gG 16

CSS 0.55-3/3-EMC 0.55 30 gG 16

CSS 0.75-3/3-EMC 0.75 30 gG 16

CSS 1.5-3/3-EMC 1.5 30 gG 16

1

Further values are available on request.
