CONTACTRON Speed Starter

128 / 150 Phoenix Contact

109908_en_02

A 4 Ambient conditions for operation, storage, and

transportation

NOTE:

This is a product for Class 1 environments (industry). The device can cause unwant-

ed radio interference if used in Class 2 environments (household). In this case, the

user may be obligated to take the necessary precautionary measures.

Do not expose the CONTACTRON Speed Starter to an unfavorable environment,

such as an environment with dust, direct sunlight, corrosive/ inflammable gases,

humidity, liquids, or excessive vibration. The salt in the air must be less than

0.01 mg/cm² per year.

Environment Installation location IEC 60364-1/IEC 60664-1 Pollution degree 2

Overvoltage category III

For indoor use only

Degree of protec-

tion

IP20/UL open type/NEMA 250 type 1

Ambient tempera-

ture

Operation -20°C ... 55°C without current derating

55°C ... 60°C with linear current derating

Storage -25°C ... 85°C

Transport -25°C ... 85°C

Non-condensing, non-freezing

Rated humidity Operation ≤90%

Storage/transport ≤95%

No water condensation

Air pressure Operation 86 kPa ... 106 kPa

Storage/transport 70 kPa ... 1106 kPa

Pollution level IEC 60721-3

Operation Class 3C2, Class 3S2

Transport Class 2C2, Class 2S2

Storage Class 1C2, Class 1S2

Concentrate prohibited

Altitude <2000 m (for altitudes >1000 m, derating necessary) Table A-8 on page 133

Package drop Storage ISTA procedure 1A (according to weight) IEC 60068-2-31

Transport

Vibration Operation 0.075 mm/1g

Compliance with IEC 60068-2-6

Non-operating
