Technical data
109908_en_02 Phoenix Contact 117 / 150
A Technical data
A 1 230 V models
A 1.1 230 V models 1-phase (without built-in EMC filter)
Housing A1 B1
MODEL CSS _ _ _-1/3 0.25 0.37 0.55 0.75 1.5
Rated power [kW/HP] 0.25/0.33 0.37/0.5 0.55/0.75 0.75/1.0 1.5/2.0
Apparent output power [kVA] 0.7 1.0 1.3 1.7 3.0
Mains rated input voltage [V AC] 1-phase 230/240
Mains input voltage range [V AC] 110 V AC ... 240 V AC (-15%/+10%)
Mains frequency range [Hz] 47 ... 63
Rated mains current [A]
Without line reactor
With line reactor
3.5
3.3
5.3
4.8
6.7
6.2
9.1
8.3
15.8
14.5
Required minimum current [A] 0.1 0.2 0.2 0.3 0.5
Rated output current [A]
At 4 kHz
At 8 kHz
At 16 kHz
1.7
1.4
0.9
2.5
2.1
1.4
3.2
2.6
1.8
4.3
3.5
2.4
7.5
6.2
4.1
Output frequency range [Hz] 0.0 ... 500.0
Power dissipation [W]
At 2 kHz
At 4 kHz
At 8 kHz
At 16 kHz
With inverter disabled
18
21
20
19
9
22
26
24
23
9
29
33
32
30
9
37
42
40
38
9
67
74
70
66
9
Overcurrent cycle 180 s
Max. output current (150% rated mains
current) [A]
Overload time [s]
Recovery time [s]
Max. output current during the recovery
time (75% rated mains current) [A]
2.55
30
150
1.275
3.75
30
150
1.875
4.8
30
150
2.4
6.45
30
150
3.225
11.25
30
150
5.625
