STO – Safe Torque Off
109908_en_02 Phoenix Contact 105 / 150
13 STO – Safe Torque Off
13.1 Defined safety function
NOTE:
The factory-installed STO bridge is installed between 24 V OUT to STO+ and GND to
STO-. When using the safety function, remove this bridge.
24V OUT (and GND) is for STO only. Do not use it for other purposes.
The safety function is defined in such a way that the motor is shut down as soon as there
is no 24 V signal on STO+ or no GND signal on STO-.
If you activate the safety function STO, the motor is not electrically isolated (electrical
safety).
The Safe Torque Off function complies with the following international standards:
– EN ISO 13849-1: Category 4 PL e
– IEC 61508: SIL 3
– IEC/EN 61800-5-2: SIL 3
– IEC 60204-1: Category 0
– IEC/EN 61800-5-2: Safety standard for drives
