ID Display on the control panel Error name Error descriptions

11 OL3 - Power component overload error CONTACTRON Speed Starter

power component overload (oL3)

The internal power components of

the CONTACTRON Speed Starter

reach the overload protection

level.

Reset

Tripping time Immediate tripping

Reset method Manual reset

Reset condition Reset after the fault is cleared.

Cause Remedial measures

CONTACTRON Speed Starter power

component overload

Enhance the heat dissipation capacity for the cabinet.

Reduce the carrier frequency (refer to parameter “Carrier frequency”

on page 81).

Replace the CONTACTRON Speed Starter with a more powerful model.

ID Display on the control panel Error name Error descriptions

12 Hot - IGBT over temperature IGBT overheating (hot) Maximum IGBT temperature exceeded

Reset

Reset method Manual reset

Reset condition Reset only when the IGBT temperature is <90°C

Cause Remedial measures

Check if the ambient temperature or

temperature inside the control

cabinet is too high, or if there is an

obstruction in the ventilation hole of

the control cabinet.

Check the ambient temperature.

Regularly inspect the ventilation hole of the control cabinet.

Change the installation location if there are heat sources in the surroundings.

Install/add a cooling fan or air conditioner to lower the temperature inside the

control cabinet.

Check if there is any obstruction on

the heatsink or if the fan is running.

Remove the obstruction or replace the cooling fan.

Insufficient ventilation space Increase the ventilation space of the CONTACTRON Speed Starter.

Check if the

CONTACTRON Speed Starter

matches the corresponding load.

Reduce the load.

Reduce the carrier frequency.

Replace the CONTACTRON Speed Starter with a model that has a higher perfor-

mance class.
