Standard fuses and circuit breakers

109908_en_02 Phoenix Contact 49 / 150

7.2.1 Circuit protection with standard fuses

The standard fuses with short circuit current ratings (SCCR) in Table 7-2 are suitable for

motor group installation.

Table 7-2 Standard fuses with SCCR (UL and cUL)

CONTACTRON Speed Starter Fuse type (UL 248)

Grid Model Power

[kW]

SCCR

[kA]

Fuse type Max. rated cur-

rent [A]

1

Min. control cabinet

dimensions [mm]

1-phase CSS 0.25-1/3 0.25 65 T, J, CC 15 500 × 400 × 250

CSS 0.37-1/3 0.37 65 T, J, CC 15 500 × 400 × 250

CSS 0.55-1/3 0.55 65 T, J, CC 15 500 × 400 × 250

CSS 0.75-1/3 0.75 65 T, J, CC 15 500 × 400 × 250

CSS 1.5-1/3 1.5 65 T, J, CC 30 500 × 400 × 250

CSS 0.25-1/3-EMC 0.25 65 T, J, CC 15 500 × 400 × 250

CSS 0.37-1/3-EMC 0.37 65 T, J, CC 15 500 × 400 × 250

CSS 0.55-1/3-EMC 0.55 65 T, J, CC 15 500 × 400 × 250

CSS 0.75-1/3-EMC 0.75 65 T, J, CC 15 500 × 400 × 250

CSS 1.5-1/3-EMC 1.5 65 T, J, CC 30 500 × 400 × 250

3-phase CSS 0.25-3/3 0.25 65 T, J, CC 15 500 × 400 × 250

CSS 0.37-3/3 0.37 65 T, J, CC 15 500 × 400 × 250

CSS 0.55-3/3 0.55 65 T, J, CC 15 500 × 400 × 250

CSS 0.75-3/3 0.75 65 T, J, CC 15 500 × 400 × 250

CSS 1.5-3/3 1.5 65 T, J, CC 15 500 × 400 × 250

CSS 0.25-3/3-EMC 0.25 65 T, J, CC 15 500 × 400 × 250

CSS 0.37-3/3-EMC 0.37 65 T, J, CC 15 500 × 400 × 250

CSS 0.55-3/3-EMC 0.55 65 T, J, CC 15 500 × 400 × 250

CSS 0.75-3/3-EMC 0.75 65 T, J, CC 15 500 × 400 × 250

CSS 1.5-3/3-EMC 1.5 65 T, J, CC 15 500 × 400 × 250

1

Further values are available on request.
