CHARX control modular product family

109999_en_05 PHOENIX CONTACT 7 / 172

2 CHARX control modular product family

2.1 Product overview of the product family

The electronics modules of the charging controllers feature the functions and interfaces re-

quired to perform a charging process in a typical AC charging station.

Charging point-specific interfaces and functions

– Interface for vehicle charging connector and infrastructure charging socket with control

of locking mechanism and automatic release of the charging connector in the event of

voltage failure

– Control of the charging contactor

– Connection option for an RFID reader for user release

– Connection option for a sensor for DC residual current detection

– Connection option for an energy measuring device to record the current charging cur-

rent and energy values

– Digital inputs with configurable function assignment

– Digital outputs with configurable function assignment

– Temperature measurement via Pt 1000 sensors or PTC chains

An embedded system with Linux operating system is also integrated in the

CHARX SEC-3xxx charging controllers. This system is the platform for the higher-level ap-

plication software used to control the charging processes and to communicate with external

systems.

The CHARX SEC-3xxx charging controller has additional communication interfaces that

can be used to connect to external systems and other charging controllers.

Table 2-1 Product overview of the CHARX control modular product family

CHARX SEC

-1000

CHARX SEC

-3000

CHARX SEC

-3050

CHARX SEC

-3100

CHARX SEC

-3150

Interfaces for operating an AC charging

point

x x x x x

Embedded system, web-based manage-

ment, OCPP, load management

x x x x

LAN/WAN Ethernet x x x x

4G cellular communication x x

ISO 15118 x x
