CHARX control modular

4 / 172

PHOENIX CONTACT 109999_en_05

1.4 Safety notes

Observe the country-specific installation, safety, and accident prevention regulations.

Installation by specialist personnel only

The charging controller is a built-in device. Installation, startup, operation, and maintenance

may only be carried out by qualified electricians. Follow the installation instructions as de-

scribed. When installing and operating the charging station for electric vehicles, the appli-

cable regulations and safety directives (including national safety directives), as well as gen-

eral technical regulations, must be observed. The safety data is provided in this manual, in

the packing slip, and on the certificates (conformity assessment, additional approvals

where applicable) in the download area for the relevant item. For example, for the item

CHARX SEC-3100, 1139012, at phoenixcontact.com/qr/1139012

Danger to life from electric shock

It may be necessary to connect to hazardous contact mains voltage to operate the charging

controller. Protection against electric shock must be ensured.

Dangerous contact voltage

You may only install and remove the device when the power supply is disconnected. Only

operate the device in a closed housing that protects against electric shock.

Provide a disconnecting device for disconnecting the charging station from the voltage.

Potentially lethal voltage

The device contains dangerous live elements and high levels of stored energy. Never carry

out work when voltage is present.

Before startup, observe the following

– Mains connection must be performed by specialist personnel. Protection against elec-

tric shock must be ensured.

– It must be possible to disconnect the device other than via the power supply in accor-

dance with the regulations of IEC 61010 (e.g., via line protection on the primary side).

– Ensure supply lines have sufficient fuse protection and are the correct size.

– Ensure output cables are the correct size for the maximum device output current or

have separate fuse protection.

– Ensure sufficient convection.

Risk of burns

The temperature of the connection terminal blocks may be increased during operation.

Electrostatic discharge

The device contains components that can be damaged or destroyed by electrostatic dis-

charge. When handling the device, observe the necessary safety precautions against elec-

trostatic discharge (ESD) in accordance with EN/IEC 61340-5-1.

Do not open or modify the device

With the exception of configuration, opening or modifying the device is not permitted. Do not

repair the device yourself; replace it with an equivalent device. Only the manufacturer is au-

thorized to carry out repairs.
