CHARX control modular
26 / 176 Phoenix Contact
109999_en_06
2.4.2 Indication elements
Table 2-3 Indication elements on the charging controller
No. Designa-
tion
Meaning Note
15 PWR
(green)
System control status Heartbeat: Embedded system in boot phase CHARX SEC-
3xxx only
On: Embedded system ready for operation
Flashing: Update active
APP (red) Application software Flashing: OCPP agent active, but no connection to
the backend
Off: OCPP agent active, connection established to
the backend
LNK (yel-
low)
Cellular connection Flashing: Modem establishing connection
On: Modem is logged in to the cellular network
BUS (blue) Backplane bus (via the DIN
rail connector)
Flashing: Addressing bus devices in the back-
plane bus
On: Module defined as the client in the backplane
bus
16 PWR
(green)
Charging interface status Flashing: Charging controller starting up
On: Charging controller ready for operation
ERR (red) Error status Flashing: Error state with an external cause (on
vehicle side, charging cable, residual current,
etc.)
On: Error state in the charging controller
CON (yel-
low)
Charging connector Flashing: Valid charging connector detected in the
charging socket
On: Charging connector locked in the charging
socket
CHG (blue) Vehicle communication Heartbeat: Vehicle connected (status B1)
Flashing: Vehicle connected, charging enabled
On: Vehicle is being charged
If all LEDs flash simultaneously, the respective controller can no longer be ad-
dressed by the CPU module. This can only be rectified with a voltage reset.
