Technical data for the DC power module

109484_en_01 PHOENIX CONTACT 85 / 94

A 3 Technical data for the DC power module

Input data

Input voltage range 3 x 400 V AC ±10%

Input current 3 x 130 A

Input frequency 3 x 50 Hz/60 Hz ±10%

Power factor (cos phi) 0.99

Total distortion (THDi) <3%

Supply system configuration, MP, and insulation

monitoring

TN-S, TN-C, TN-C-S, IT (PE)

Output data

Output voltage range 200 V DC ... 920 V DC ±1%

Output current 125 A, maximum

Output current residual ripple ≥1%

Efficiency 97%, maximum

Nominal power 87.5 kW

Output power 87.5 kW, maximum

Power dissipation <2650 W

Power dissipation, standby <135 W

General data

Degree of protection/protection class IP20/I

Pollution degree 2

Ventilation



Noise level (at full load) 72 dB, approximately

Hot plug connection



IEC 60664-1 overvoltage category II

Ambient temperature (operation) 0°C ... 50°C (derating >40°C: 2.5%/K)

Permissible humidity (operation), non-condensing 5% ... 95%

Ambient temperature (storage/transport) -25°C ... 85°C

Altitude ≤2000 m (derating >1000 m: 10%/1000 m)

Dimensions (W x H x D) 536 mm x 222 mm x 600 mm

Weight 58 kg
