CHARX PS...87.5KW

84 / 94 PHOENIX CONTACT 109484_en_01

A 2 General system data

General system data

DC power modules/charging points 2 or 4

Dimensions (W x H x D) 600 mm x 1800 mm x 800 mm

Weight 200 kg cabinet

432 kg cabinet with four modules

Cable entry (system control cabinet) Bottom (top on request)

Degree of protection IP20 (IP21 on request)

Maximum battery charging current per

charging point

2 x 250 A with two charging points

500 A with one charging point

Pollution degree 2

Protection class I

Overvoltage category (CAT) II (III on request)

Insulation According to IEC 60664-1

Cooling Forced ventilation: The fans are temperature-controlled and monitored. The

system integrator has to guarantee correct air exchange, heat dissipation

and temperature control within the specified temperature range in the oper-

ating room.

Supply air temperature of the cabinet -5°C ... 40°C; reduced performance above this temperature

Limited performance above 40°C 12.5% per 5 K (50°C, maximum)

Volumetric air flow 2500 m³/h (without air pressure loss)

Noise level 77 dB (A) with four modules and at full load

Relative humidity 0% ... 95% (non-condensing)

Storage temperature -40 C ... 85°C

Installation altitude Up to 1000 m above sea level (ASL), no restrictions

Above 1000 m above sea level, reduced performance of 10% per 1000 m

Maximum altitude: 2000 m

Floating contact In the system control cabinet, a floating contact is controlled redundantly by

the modules: charging unit collective alarm

Additional alarms are available on the CAN bus and are part of the system

monitoring

External functions (digital inputs) 2 x remote OFF (1 x per charging point)

Analog input 1 x temperature

Standards The system control cabinet is designed in compliance with:

– IEC 61851-1

– IEC 61851-23

– IEC 61851-21-2

Certification of the entire system lies within the responsibilities of the system

integrator.
