8663_en_08 PHOENIX CONTACT 3 / 38
Table of contents
1 For your safety .............................................................................................................................4
1.1 Labeling of warning notes .......................................................................................4
1.2 Qualification of users ..............................................................................................4
2 Diagnostics in the Axioline F system ...........................................................................................5
2.1 Local diagnostic and status indicators ...................................................................5
2.1.1 D and E indicators on controllers and bus couplers ...............................6
2.1.2 Indicators on I/O modules and backplanes ...........................................7
2.2 Diagnostics via object 0018
hex
(DiagState)......................................................... 11
2.3 Diagnostic registers of the local bus master ....................................................... 15
2.3.1 Diagnostic status register ..................................................................... 15
2.3.2 Diagnostic parameter registers ............................................................ 17
2.4 Diagnostic registers of the AXC ... controllers..................................................... 18
2.5 Diagnostic registers of the AXL F BK ... bus couplers.......................................... 19
3 Error codes ................................................................................................................................ 20
3.1 Error codes for user errors ................................................................................... 20
3.2 Error codes for bus diagnostics ........................................................................... 25
3.3 Error codes when invoking the PDI services ....................................................... 27
3.4 Error codes of the I/O modules............................................................................ 32
