Diagnostics in the Axioline F system
8663_en_08 Phoenix Contact 13 / 38
.09 AddValue Octet string 4 Additional
information
“Additional value” for the current diagnostic
state of the device.
.0A TextLength UINT8 1 Text length Length of the following diagnostic text in bytes.
.0B Text Visible string Max. 100 Diagnostic
text
Device-specific explanation of the malfunction
that occurred.
Information includes:
– Error type
– Function group and channel
– Terminal point
– Option for action for the user
Default: “Status OK”
The string is terminated with 00
hex
.
Table 2-5 Objects for diagnostics: Diagnostic state (read) according to basic profile V3.x [...]
Index
[hex]
Object name Data type Length in
bytes
Meaning
Table 2-6 Index 5: Additional information
Byte/bit Value Meaning
Byte 00
hex
No further information
Bit 0 1 There is further information about this error. You can read it via
object E800
hex
“DiagStateLong” (if implemented).
Bits 1 ... 3 0 Reserved
Bit 4 1 There are additional simultaneously occurring diagnostic
events. You can read them via object E806hex “ComplDiag-
State” (if implemented).
Bits 5 ... 6 0 Reserved
Bit 7 1 Indication that this is an extended version of object 0018
hex
(compared to version V2.x).
Table 2-7 Classification of the error messages
Priority Message type Example Note
01
hex
High Error
(malfunction,
alarm)
Supply voltage faulty
Parameter table invalid
A malfunction has occurred that requires a
response.
For example, a malfunction requires action
in the drive, but does not necessarily require
the system to be stopped with immediate
effect.
02
hex
Medium Warning Limit value undershot or ex-
ceeded
Risk of an error.
A warning does not require action to be
taken in the device.
03
hex
Low Information (mes-
sage, notification)
General operating message:
10,000 operating hours have
elapsed.
General operating message: 10,000 operat-
ing hours have elapsed.
