7
2. Setting up the monitor
Description of the On Screen Display
What is On-Screen Display (OSD)?
On-Screen Display (OSD) is a feature in all
Philips LCD monitors. It allows an end user
to adjust screen performance or select
functions of the monitors directly through
an on-screen instruction window. A user
friendly on screen display interface is
shown as below:
Basic and simple instruction on the control
keys
To access the OSD menu on this Philips
display simply use the single toggle button
on the rear side of the display. The single
button operates like a joystick. To move
the cursor, simply toggle the button in
four directions. Press the button to select
desired option.
The OSD Menu
Below is an overall view of the structure of
the On-Screen Display. You can use this as
a reference when you want to work your
way around the dierent adjustments
later on.
Game
Setting
LowBlue
Mode
Input
OSD Setting
Setup
Language
Color
Audio
Horizontal
Vertical
Transparency
OSD Time Out
English, Deutsch, Español, Ελληνική, Français, Italiano, Magyar，
Nederlands, Português, Português do Brasil，Polski，Русский ,
Svenska，Suomi，Türkçe，Čeština，Українська, 简体中文,
繁體中文，日本語，한국어
Color Temperature
sRGB
User Dene
SmartImage
SmartImage HDR
SmartFrame
MPRT Level
MPRT
Brightness
Contrast
Sharpness
SmartContrast
Gamma
DisplayPort
2 HDMI 2.0
1 HDMI 2.0
0~100
0~100
O, 1, 2, 3, 4
5s, 10s, 20s, 30s, 60s
Native, 5000K, 6500K, 7500K,
8200K, 9300K, 11500K
Red: 0~100
Green: 0~100
Blue: 0~100
0~100
On, O
0~20
SmartResponse
Low Input Lag
O, Fast , Faster, Fastest
On, O
On, O
Adaptive Sync
On, O
O
On
1, 2, 3, 4
On, O
Information
Reset
Yes, No
On, O
Resolution
Notication
Size: 1, 2, 3, 4, 5, 6, 7
Brightness: 0~100
Contrast: 0~100
H. position
V. position
FPS/Racing/RTS/Gamer1/Gamer2/
LowBlue Mode/EasyRead/O
HDR Game/HDR Movie/HDR Photo/
Personal/O
0~100
0~100
0~100
On, O
1.8, 2.0, 2.2, 2.4, 2.6
Volume
Audio Source
HDMI 1, HDMI 2, DisplayPort
Mute
On, O
Over Scan
On, O
PIP/PBP
PIP / PBP Mode
PIP / PBP Input
PIP Size
PIP Position
Swap
O, PIP, PBP
1 HDMI 2.0, 2 HDMI 2.0, DisplayPort
Small, Middle, Large
Top-Right, Top-Left, Bottom-Right,
Bottom-Left
Panel Size
SmartSize
1:1
Aspect
19'' (5:4)
19''W (16:10)
22''W (16:10)
23''W (16:9)
18.5''W (16:9)
21.5''W (16:9)
27''W (16:9)
24''W (16:9)
19.5''W (16:9)
20''W (16:9)
17'' (5:4)
Main menu Sub menu
Auto
34''W
