User Manual BDH5031V
DIGITAL
AUDI
O
OPTICAL
INPUT
PC AUDIO
SERVICE
PC IN
PC OUT
AUDIO
HDMI
COMPONENT
INPUT
AV1 AV2
AUDIO
VIDEO
DIGITAL
AUDI
O
OPTICA
L
INPUT
PC AUDIO
SERVICE
PC IN
PC OU
T
AUDIO
HDMI
COMPONENT
INPU
T
AV1 AV2
AUDIO
VIDEO
MENU
MOVE
Component
Video
Audio
Digital Broadcasting
Receiver
(Set-Top Box)
AV 1
AV 2
AV 3
Component
PC
HDMI
Sound
Screen
Feature
Input
Move Select Exit
RETURN TO THE CONTENTS
5. CONNECTING WITH AN EXTERNAL SOURCE
5.1 WATCHING DIGITAL BROADCASTS
• To watch digital broadcasts:
- Purchase a separate Digital Broadcasting Receiver (SET-TOP BOX).
- Connect the PDP to a Digital Broadcasting Receiver as shown left.
1. Connect a Digital Broadcasting Receiver to the PDP.
• Prepare A/V cables.
• Connect the cables from the digital TV Receiver output terminal to the
PDP (Component ) input terminal.
• When connecting the cables, be sure to match the cable colours.
2. Press the Power Buttons.
• Turn the PDP and the receiver ON.
3. Input Select.
• Select [Component] by pressing the “AV” button of the remote control
or using the button of the PDP unit.
• When you press the “AV” button, you will see the OSD as shown. You
can move using “/“ and select desire input mode with “/“ but-
ton.
4. Select the Desired Channel and Function.
• Select the desired channel and function by using the remote control
of the Digital Broadcasting Receiver.
Notes:
1) Possible digital broadcasting signals: 1080i, 720p, 576p, 576i, 480p, 480i.
2) What is a component? : Signals with which luminance and chrominance
are separated, producing a sharp picture.
3) If the Digital Broadcasting Receiver has PC output terminal or HDMI
output terminal, connect to ‘PC INPUT’ or ‘HDMI INPUT’ at the rear of the
panel of the PDP.
