the HDMI cable to an HDMI ARC/eARC connection on

the Home Theater System.

• Make sure that the TV audio output is connected to

the audio input on the Home Theater System.

Sound should be heard from the HTS (Home Theater

System) speakers.

Sound with loud noise

If you watch a video from a plugged in USB flash drive

or connected computer, the sound from your Home

Theater System might be distorted. This noise is heard

when the audio or video file has DTS sound but the

Home Theater System has no DTS sound processing.

You can fix this by setting the Digital out format of the

TV to Stereo.

Press (Home) > Settings

> Sound > Advanced > Digital out format

20.7. HDMI - UHD

HDMI

• Note that HDCP (High-bandwidth Digital Content

Protection) support can delay the time taken for a TV to

display content from an HDMI device.

• If the TV does not recognize the HDMI device and no

picture is displayed, switch the source from one device

to another and back again.

• This is an Ultra HD TV. Some older devices - connected

with HDMI - do not recognize an Ultra HD TV

electronically and might not work correctly or show

distorted picture or sound. To avoid the malfunctioning

of such a device, you can set the signal quality to a level

the device can handle. If the device is not using Ultra

HD signals, you can switch off Ultra HD for this HDMI

connection.

If the picture and sound of a device connected with

HDMI is distorted, check if a different HDMI Ultra

HD setting can solve this problem. You can check on

Help > User manual > General Settings > HDMI Ultra

HD.

• If there are intermittent sound disruptions, make sure

that output settings from the HDMI device are correct.

HDMI EasyLink does not work

• Check if your HDMI devices are HDMI-CEC compatible.

EasyLink features only work with devices that are HDMI-

CEC compatible.

HDMI eARC is not working well

• Make sure the HDMI cable is connected to HDMI 1.

• Make sure an Ultra High-Speed HDMI cable is used

for eARC connection.

• Only one eARC device is available at a time.

No volume icon shown

• When an HDMI-CEC audio device is connected and

you use the TV Remote Control to adjust the volume

level from the device, this behavior is normal.

20.8. USB

Photos, videos and music from a USB device do not

show

• Check if the USB storage device is set to Mass Storage

Class compliant, as described in the storage device's

documentation.

• Check if the USB storage device is compatible with the

TV.

• Check if the audio and picture file formats are

supported by the TV. For more information, check on

Help > User manual > Specifications > Multimedia.

Choppy playback of USB files

• The transfer performance of the USB storage device

may limit the data transfer rate to the TV which causes

poor playback.

20.9. Wi-Fi and Internet

Wi-Fi network not found or distorted

• Check if the firewalls in your network allow access to

the TV's wireless connection.

• If the wireless network does not work properly in your

home, try the wired network installation.

Internet does not work

• If the connection to the router is OK, check the router

connection to the Internet.

The PC and Internet connection are slow

• Look in your wireless router's user manual for

information on indoor range, transfer rate and other

factors of signal quality.

• Use a high-speed (broadband) Internet connection for

your router.

DHCP

• If the connection fails, you can check the DHCP

(Dynamic Host Configuration Protocol) setting of the

router. DHCP should be turned on.

20.10. Wrong Menu

Language

Change the language back to your language

1 - Press  Home and select Settings via the icon at the

top-right corner.

2 - Press  (down) 8 times and press OK.

3 - Press OK again to enter Language, select the first

item Menu language and press OK.

4 - Select your language and press OK.
