Philips 3000 Series 32BDL3751T Handleiding (83 Pagina's)

Handleiding

32BDL3751T

24

4.2.3. Using HDMI input with USB-B (touch connector to PC)

PC

HDMI IN

HDMI OUT

[HDMI IN]

[USB-B]

[USB]

USB-B

4.3. Connecting Audio Equipment

4.3.1. Connecting an external audio device

Stereo Ampli�er

[AUDIO OUT]

AUDIO IN

AUDIO OUT

4.4. Connecting Multiple Displays in a Daisy-Chain Configuration

You can interconnect multiple displays to create a daisy-chain conguration for applications such as a menu board.

4.4.1. Display control connection

Connect the [RS232 OUT] connector of DISPLAY 1 to the [RS232 IN] connector of DISPLAY 2.

PC

DISPLAY 2

DISPLAY 1

[RS232 IN]

[RS232]

[RS232 OUT] [RS232 IN]

PC

[RJ-45] [RS232 OUT] [RS232 IN]

DISPLAY 1 DISPLAY 2

[RJ-45]
