11
2.3 Remove the Base Assembly
for VESA Mounting
Before you start disassembling
the display base, please follow the
instructions below to avoid any possible
damage or injury.
1. Place the monitor face down on a
smooth surface. Pay attention not to
scratch or damage the screen. Then
lift the monitor stand.
2. While keeping the release button
pressed, tilt the base and slide it out.
3. Press both corners of the VESA Cover
and the other side of the cover will
pop out.
4. Loosen the assembly screws, Remove
the hinge.
Note
This monitor accepts a 100mm x 100mm
VESA-Compliant mounting interface. VESA
Mounting Screw M4. Always contact the
manufacturer for wall-mount installation.
100mm
100mm
-5°
0° 90°
* Display design may dier from those
illustrated in this manual.
Warning
• To avoid potential screen damage,
such as panel peeling, ensure that the
monitor does not tilt downward by
more than -5 degrees.
• Do not press the screen while adjusting
the angle of the monitor. Grasp only
the bezel.
