Copyright © 2020, Fast ČR, a. s. Revision 12/2020

EN - 10

2. Connection between screw tap and inlet hose.

slide bushing

Tap with threads and inlet hose Special tap for washing machine

Connect the other end of inlet pipe to the inlet valve at the backside of product and fasten the pipe tightly

clockwise.

water Inlet valve

water supply hose

Drain Hose

！

Warning!

t %POPULJOLPSQSPUSBDUUIFESBJOIPTF

t 1PTJUJPOESBJOIPTFQSPQFSMZPUIFSXJTFEBNBHFNJHIUSFTVMUPGXBUFSMFBLBHF

There are two ways to place the end of drain hose:

Min.60cm

100cm

Max.

1. Put it into the water trough. 2. Connect it to the branch

drain pipe of the trough.

Water

trough

Note!

t *GUIFNBDIJOFIBTESBJOIPTFTVQQPSUQMFBTFJOTUBMMJUMJLFUIFGPMMPXJOH
