EN - 20
Failure Problem Solution A Solution B
Heating stops suddenly
during operation and the
display ashes “U”.
Pan Type is wrong. Use the proper pot
(refer to the instruction
manual.)
Pan detection
circuit is damaged,
replace the power
board.
Pot diameter is too
small.
Cooker has overheated; Unit is overheated.
Wait for temperature to
return to normal.
Push “ON/OFF” button to
restart unit.
Heating zones of the same
side ( Such as the rst and
the second zone ) would
display “U” .
The power board and
the display board
connected failure;
Check the connection.
The display board of
communicate part is
damaged.
Replace the display
board.
The Main board is
damaged.
Replace the power
board.
Fan motor sounds abnormal. The fan motor is
damaged.
Replace the fan.
The above are the judgment and inspection of common failures.
Please do not disassemble the unit by yourself to avoid any dangers and damages to the induction hob.
9. INSTALLATION
9.1 Selection of installation equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 50mm space shall be preserved around the hole.
Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant and insulated work
surface material (Wood and similar brous or hygroscopic material shall not be used as work surface material
unless impregnated) to avoid the electrical shock and larger deformation caused by the heat radiation from
the hotplate. As shown below:
Note: The safety distance between the sides of the hob and the inner surfaces of the worktop should
be at least 3mm.
