Flat Top Bottle Coolers Installation & Operation Manual
Printed in USA 9
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without prior notice.
REPLACEMENT PARTS
-
FLAT TOP BOTTLE COOLERS
MODEL NOS. BC24 BC36
BC48/
BC48LT
BC60/
BC60LT
BC72/
BC72LT
BC96
Item Description Part Numbers
1 Complete condensing unit C22648 C22648 C22647 C22646 C22646 C22646
2 Replacement compressor, R134a 513307046 513307046 513200314UA2 513200003 513200003 513200003
Condensing unit fan motor assy. 515315009 515315009 515315009 515315009 515315009 515315009
Terminal Board 519100088 519100088 519100088 519100088 519100088 519100088
Overload Protector 513634530 513634530 US-PB10HBX1 US-PB12HBX1 US-PB12HBX1 US-PB12HBX1
Relay 513514069 513514069 US-PB10HBX1 US-PB12HBX1 US-PB12HBX1 US-PB12HBX1
Start capacitor N/A N/A US-PB10HBX1 US-PB12HBX1 US-PB12HBX1 US-PB12HBX1
3 Condensate pan 64537 64626-1 64626-1 64626-1 64626-1 64626-1
4 Evaporator fan motor(s) C15239A C15239A C15239A C15239A C15239A C15239A
5 Evaporator fan motor bracket 65671-1 65671-1 60988-1 60988-1 60988-1 60988-1
6 Evaporator fan motor blade 63461 63461 57699 57699 57699 57699
7 Evaporator fan guard 65666 65666 65557 65557 65557 65557
8 Evaporator coil 64785-1EP C17511-1EP C17511-1EP C17511-2EP C17511-2EP C17511-2EP
9 Temperature control 61283 61283 61283 61283 61283 61283
10 Bottle opener C6713-1 C6713-1 C6713-1 C6713-1 C6713-1 C6713-1
11 Bottle cap receiver C17332SS C17332SS C17332SS C17332SS C17332SS C17332SS
12 Front grille 66498-3A 65662-1A 65662-A1 65662-1A 65662-1A 65662-1A
13 Rear grille/panel 66498-1 65662-3 65662-3 65662-3 65662-3 65662-3
14 Top assembly RT-SL2 RT-SL2 RT-SL2 RT-SL2 RT-SL2 RT-SL2
15 Top wiper gasket 63671-24 63671-36 63671-48 63671-60 63671-72 63671-96
16 Door assembly RD-SL2 RD-SL2 RD-SL2 RD-SL2 RD-SL2 RD-SL2
17 Lock assembly 63940 63940 63940 63940 63940 63940
18 Vertical partition 65503 66441 66441 66441 66441 66441
19 Roller basket N/A 66442-1 66442-1 66442-1 66442-1 66442-1
20 Wide shelf N/A 64811-1 64811-1 64811-1 64811-1 64811-1
21 Narrow shelf 64809-1 64809-1 64809-1 64809-1 64809-1 64809-1
22 Bottom oor rack (wide) 64814-1 64814-1 64814-1 64814-1 64814-1 64814-1
23 Bottom oor rack (narrow) N/A N/A 64815-1 64815-1 64815-1 N/A
24 Shalf bracket 65653-24 65653-36 65653-48 65653-60 65653-72 65653-96
25 Door handle 63931 63931 63931 63931 63931 63931
26 Light Bulb C15046 C15046 C15046 C15046 C15046 C15046
27 Light socket 63484 63484 63484 63484 63484 63484
28 Evaporator drain pan 65670-24 65670-36 65526-1SL 65526-2SL 65526-2SL 65526-2SL
ITEMS NOT SHOWN
Wire harness, main 65043-1 65043-1 65044-1 65044-1 65044-1 65044-1
Suction line/cup tube heat
exchanger with drier
65072 65072 65073 65075 65074 65220
Mullion assembly N/A N/A 66551 66551 66551 66551
Refrigerant charge (oz. R134a) 6.0 8.5 9.0 9.0 9.0 9.0
