Flat Top Bottle Coolers Installation & Operation Manual
Printed in USA 4
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without prior notice.
PREPARING THE CABINET
-
FLAT TOP BOTTLE COOLERS
Uncrating and Inspection
Remove all crating material. Carefully inspect
cabinet for hidden damage. If damage is
discovered, le your claim immediately with the
transport company. Perlick is not responsible for
damage in transit.
Plumbing
No plumbing connections are required.
Condensate from the cooling coil automatically
evaporated through a condensate pan located in
the condensing unit section.
Electrical
The cabinet must be connected to a separately
fused power source (see Electrical Specication
Plate axed to unit) in accordance with National
and Local electrical codes.
CAUTION
Do not attempt to operate
the equipment on any
other power source than that listed on the
Electrical Specication Plate.
Adjustable Partitions & Shelving
Perlick Bottle Coolers may be provided with
adjustable partitions and shelving which will
accommodate various bottle sizes.
■ Remove bottles and cans from their cases
before placing in cooler to ensure proper
air ow.
■ On 2’ and 3’ models keep air intake open for
proper circulation.
Installing Casters or Legs (optional)
Attach casters or legs to the cabinet bottom in
holes provided. Use the supplied 1/4” - 20 hex
head self-tapping machine screws. If unit is tipped
on its back for an extended period of time, wait
24 hours after unit is uprighted to plug the unit in.
Placing the Cabinet
To assure maximum performance, fresh air must
be allowed to circulate through the machinery
compartment. It is important to allow at least
two inched of clearance at the back or left end
of the cabinet. Do not place anything in front of
the cabinet that would obstruct air ow at these
grilles. Do not place the unit in an unventilated
small room.
CAUTION
Removing the factory
installed back clearance
spacers without providing proper left side grill
clearance for compressor air ow will void the
warranty.
Cabinet should be leveled.
For sanitation purposed, it may be necessary to
seal the base of the cabinet to the oor. This can
be accomplished by laying a bead of silicone
sealant along the base of the cabinet as shown
by the gure below (gure 1).
Cabinet
Bead Silicon
Sealer (RTV)
Floor
Figure 1. Sealing Cabinet to Floor
