Ice Cream Cabinet Installation & Operation Manual
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without prior notice
5
Form No. Z2643
Rev. 11.02.21
Preparing the Cabinet for Use
PLACING THE CABINET
IMPORTANT: The unit must NOT be totally
enclosed. In addition to the clearances required
around the condensing unit below, there must be
at least one opening (minimum size 15”X15”) to
allow for air circulation . This is important to ensure
that the hot air that is being exhausted from the
unit has a place to escape and allow fresh air in.
The condenser and cabinet front must be provided
with a minimum of two inches air space. Be sure
COOLING SYSTEM
This cabinet maintains temperatures from the cold
walls of the storage compartment. If excessive frost
accumulates on the walls, remove the plug from the
electrical outlet. Never use a sharp instrument to
break ice from the cabinet walls.
Digital Temperature Control
To display the Set point values press the key
when the ‘SET’ label is displayed. The Set point
value appears on the display. To change the Set
point value, press the and keys within 15
seconds. Press to conrm the modication.
The condenser fan motor turns o and on with
compressor. The evaporator fan motor runs
continuously.
Figure 2: Digital Temperature Controller
to provide access so front cover of drop-in ice
cream cabinet can be removed to clean the
condenser. Other required minimum installation
clearances are: 2.5” on left side, 2.5” on right
side, 4.5” on rear side, and 6” between bottom
of freezer and floor.
After placing the cabinet into its initial
operation, allow about 24 hours for the cabinet
to reach and maintain proper temperature.
How To Operate
OILING
The system is sealed and the compressor
requires no oiling.
Cleaning
Condenser
DANGER
Flammable Refrigerant.
Risk of re or explosion.
Do not damage refrigeration tubes.
■ The condenser (located behind the front
grille) should be inspected every 30 days,
and cleaned, if necessary. Condenser
should be cleaned using a soft bristled brush
and vacuum. Failure to keep the condenser
clean will cause a loss in condensing unit
eciency, or compressor failure.
Cabinet
Use a damp cloth with mild detergent and
water to clean the inside and outside of the
cabinet. Dry thoroughly.
