13
(Continued)
OPERATION INSTRUCTIONS
Emptying the condensate tank:
1. Shut o the air conditioner by pressing the power switch to the “O” position.
2. Locate the condensate tank.
3. Remove the condensate tank and empty the contents.
4. Re-install the condensate tank after emptying, making sure it is properly aligned.
5. Power on the unit. There is a 3-minute delay for the compressor to start.
Normal operation will resume after time delay has ended.
6. Empty the condensate tank before moving the air conditioner to avoid any spills.
ADJUSTMENT RANGE AND OPERATION OF THE AIR DIRECTION
• The cold air duct can rotate around 360 degrees
• The cold air duct can be moved up and down by about 150 degrees.
CONDENSATE TANK
ATTENTION: When adjusting the air outlet
angle of the cold air duct, please hold the
elbow for adjustment. Do not directly hold
the cold air duct for adjustment.
ATTENTION: The compressor has a 3-minute safety delay function. After emptying the tank,
there will be a 3-minute delay where only the fan will operate. After the 3-minutes have expired,
the compressor will activate and normal operation will resume.
• If the unit has not been operated for a long time, check the condensate tank before operating:
• Remove the condensate tank from the air conditioner and conrm the oat device inside the tank
is intact. If no issues are found with the oat device, re-install the condensate tank into the air
conditioner, making sure everything is aligned.
• Improper installation of the condensate tank may trigger the condensate alarm, unit malfunction,
or condensate leakage.
