24 - GB
illuminate and a message "NO SIGNAL" will appear on the display
monitor. In this case relocate the transmitter and receiver, reducing the
distance if possible. If there is still no connection then the transmitter and
receivermustbepairedagain(seechapter10.1).
Ifthevideostopsordoesnotrunsmoothlyadjusttheantennas,changethe
positionsorreducethedistancebetweenthetransmitterandreceiver.
A visual indication of the connection quality can be obtained after
removing the mains adapter [20] of the receiver from the mains supply
and then reconnecting this. A symbol with 0 to 4 bars will then show for
approx. 10 seconds in the top right hand corner of the picture on the
displaymonitor.
The transmitter [1] and receiver [11] must be paired with each other to
establishthewireless connection. The transmitterdeliveredintheset is already
pairedwiththereceiver.
Ifrequiredthewirelessconnectioncanbeestablishedasfollows:
Checkthatthecablesarecorrectlyconnected,thattransmitterandreceiver
arepowered(powerLEDs[2and12]illuminateonthereceiverDF-120RX)
andthatthesearelocatedwithinthewirelessrange.
Holdthe"Pairing"-button[19] presseduntiltheconnection
LED [14] flashes. On the display monitor the following message appears:
"PleasepresspairingbuttonofTXdevice"andatimercountsdownfrom60
seconds.
Within the 60 seconds you have time to establish the connection as
follows. Press and hold the "pairing"-button [9] DF-
120TX until the connection LED [4] on the transmitter flashes. When
wireless connection is sucessfully established the following message will
appear on thedisplay monitor: "Pairing OK savedata". This message will
disappearafterapprox.10 secondsandthepicturefromtheAV-sourcewill
appear.TheconnectionLEDs[4and14]willilluminategreen.
If the source device has an infrared remote control this can be used from the
#
#
!
!
!
10. Functions
10.1 Connectionpairing
10.2 UsinganInfraredRemoteControl
onthereceiver
on the transmitter
8. Connection
9. Operation
Connectionofthetransmitter
Connectionofthereceiver
!
!
!
!
!
!
!
!
#
Connect the AV-input [8] of the transmitter DF-120TX [1] with the AV-
output of the source device using the AV cable [6] (yellow plug=video /
red plug=audio right / white plug= audio left). If required use
cinch/BNC adapters or an cinch/scart adapter (see chapter 15).
ConnecttheDC-plugofthemains adapter cable [10] to the mains adapter
connection[7]ofthetransmitter.
Connect the mains adapter with a suitable mains outlet. The power-LED
[2]andtheconnection-LED[4]illuminateandafterapprox.3secondsthe
connection-LEDisextinguished.
Connect the AV-output [18] of the receiver DF-120RX [11] with the AV-
input of the source device using the AV cable [16] (yellow plug=video /
redplug=audioright/whiteplug=audioleft).
ConnecttheDC-plugofthemains adapter cable [20] to the mains adapter
connection[17]ofthetransmitter.
Connect the mains adapter with a suitable mains outlet. The power-LED
[12] and the connection-LED [14] illuminate and after approx. 3 seconds
the connection-LED is extinguished. If wireless connection is established,
thentheconnection-LEDwillilluminateafterapprox.4seconds.
Afterconnectionofthepowersuppliesthesetisinoperation.
Switchonthepowerforthesourceanddisplaydevices.
Select the AV input corresponding to the connection (on some TV sets this
may be depicted as VCR, channel 0, or with the symbol). If a
camera is connected through a recorder then select the corresponding AV
channel. You will now see the picture and hear the sound from the source
device.
The orientation ofthe antennas [5 and 15] can be adjusted to achieve the
bestpossibleconnectionquality.
If there is no wireless connection the connection-LEDs [4 and 14] will not
Note:
!
!
