GB - 21
receive the synchronised signals. This security feature is designed to prevent
accesstothetransmittedsignalbythirdparties.
Themaximumrangeofthewirelesssignalinopenspacesistypically100m(up
to 200m in optimal conditions) with line of sight contact between transmitter
and receiver. Withinbuildings the range is greatlyreduced by walls and floors,
inparticularthosemadeofsteelreinforcedconcrete,toatypicallyabout20m.
The power is supplied through the supplied mains adapters connected to a
230VAC,50Hzmainssupply.
The components are for indoor use only and must be protected from moisture.
Thesetisforuseinprivatehouseholds.
Anyotheruse or modification of thedeviceisnotauthorised.No liability will be
acceptedforconsequential damages or for damagescausedbyimproperuseor
incorrect operation. No liability will be accepted for consequential damages
caused by any function or by malfunction. Unless any liability is specifically
required by law, claims for damages, in particular those for personal injury or
property damage caused by non-functioning or malfunctioning of the device,
areexcluded.
This appliance is not intended to be used by people (including children) with
restricted physical, sensoryor mental capacities,or a lackof experience and/or
knowledge,unlesstheyaresupervisedby,orreceiveinstructionshowtousethe
appliancefromapersonresponsiblefortheirsafety.
DF-120TXtransmitter
DF-120RXreceiverwithconnectioncables
2xconnectioncableswithCinch(RCA)plugs(video,audioL/R)
2xmainsadapter5VDC
usermanual
3. Packagecontents
!
!
!
!
!
(seeFig.AandB)
Operatinginstructions
1. Introduction
2. Properuse
The digital wireless transmission set consists of the transmitter DF-120TX and
receiverDF-120RXeachwithamainsadaptor.
This system is intended to be used for the wireless transmission of video and
audiosignalsfrom anAudio/Video(A/V)sourcedevice.Itcanbeusedwith,for
example, a satellite receiver, DVD players, VCR, camcorder or projector with
analoginput/output,CCTV-camerasetc.
The A/V source (from a DVD player for example) input into the transmitter is
converted to a digital wireless signal which is transmitted in the 2.4 GHz
frequency band. The receiverconverts this signalback to analogA/V signals as
outputtoadisplaydevice(forexampleaTVset).
The receiver also has the ability to transmit infrared remote control signals. In
this case the original remote control of the A/V source device can be used with
thereceiver, and thetransmitterwillrelay theinfraredsignalsto the A/Vsource
device.
Forexample: WiththeDF-120 setitispossible towatchfor exampleSAT-TV in
a room without a wired SAT connection and to control the SAT-Receiver or TV
usingtheoriginalInfraredremotecontrol.
The wireless transmission is digital and on constantly changing frequencies
(frequency hopping) which are synchronised between the transmitter and the
receiver. Only the receiver which has been "paired" with the transmitter can
Read through these operating instructions fully and carefully. The operating
instructions belong to this product and contain important points concerning
bringingtheapplianceintoserviceanditsoperation.
Always pay attention to all safety instructions. Should you have any questions
or be unsure about operating the appliance ask a specialist. Keep these
instructions in a safe place and should the need arise pass them on to a third
party.
