GAS CHICKEN ROTISSERIE
G HOW TO CHANGE THE TYPE OF GAS?
This operation can only be performed by authorized personnel!!! Follow the steps below to
change the gas type.
a) Make sure that the mains valve to the rotisserie is closed.
b) Remove the regulator arms (1)
c) Loosen the housing cover screws and remove the cover.
d) Loosen nuts number 2 and pull out the pipe (Fig. 1)
e) Pull out the injector holder no.6. Venturi assembly no.6 and injector are now outside the
burner.(Figure 2)
f) Disconnect the no.3 elbow from the no.6 assembly by removing the elbow.
g) Replace injector number 4 with an injector suitable for the type of gas to be used. The
injector diameter is marked on the injector body. Make sure it is the correct injector! (Figure
2) replace the injector with a new one.
h) After the change has been made, reverse the process without skipping any steps.
i) Before installing the side cover, install all control knobs. Light one burner Repeat this step for
each burner. Make sure there are no leaks!
j) Replace the label showing the gas type and pressure with the new label included in the
injector kit.
4
(Fig. 2)
(Fig. 1)
1
2
3
6
