12
2022-07-06 #:180-9147-1
Example of brackets installed with
600mm x 600mm mounting position.
Portrait Mounting
Portrait oriented displays can use either 400mm x 400mm VESA mounting patterns on the raised portion of the rear
surface. Note, this may limit access to removable input cover. Installers can also use either a 600 x 600mm mounting
pattern or the 600 x 850mm perimeter mounting locations.
Four M8 x 35mm screws and
mount sold separately.
Do not overtighten.
Maximum 45 in. • lb (5 N.M.).
