pattersonfan.com
800.768.3985
15
RUN INPUT POWER CABLE & INSTALL LOCKABLE
DISCONNECT
WARNING: The Lockable Disconnect must be installed per local electrical codes. AT MINIMUM it must be installed
outside the diameter of the fan blades.
1
Be sure to size the input power cable properly for the application. Most installations will require 12-gauge wire. However, longer
runs of power cable may require 10-gauge or higher.
2
Run input power into the top of the Lockable Disconnect, using the appropriately sized knockout.
3A (THREE PHASE)
Connect conductors to terminals L1, L2, and L3, respectively. Ground wire should be fastened to one of the ground terminals.
Continue running input power to the drive by connecting three conductors to terminals T1, T2, and T3, respectively. A ground wire
should be fastened to the ground terminal.
3B (SINGLE PHASE)
Connect conductors to terminals L1 and L2, respectively. Ground wire should be fastened to one of the ground terminals. On the
output side, T2 should be looped back to input L3. Continue running input power to the drive by connecting two (2) conductors to
terminals T1 and T3, respectively. A ground wire should be fastened to the ground terminal.
4
Run the rest of the input cable near the wall mounted VFD. Using conduit for this run is recommended.
5A (THREE PHASE)
Connect the opposite end of the input power cable to the VFD. The three conductors should be connected to L1, L2, and L3,
respectively. The ground wire should be connected in the manner shown in Image 19.
5B (SINGLE PHASE)
Connect the opposite end of the input power cable to the VFD. The two conductors should be connected to L1/L and L2/N,
respectively. The ground wire should be connected in the manner shown in Image 20.
6
Reconnect Cat5 keypad cable to VFD and reattach cover.
ELECTRICAL INSTALLATION
