WARNING

Disconnect power source before installing or servicing. Failure to disconnect power source can result in ﬁre, shock or serious injury.

1. Patterson products should be installed and serviced by qualiﬁed technicians only.

2. Follow all local electrical and safety codes, as well as the National Electric Code (NEC) and the Occupational Safety and Health Act (OSHA) in the United

States.

3. The unit should be installed, protected and fused in accordance with latest issue of the National Electrical Code, MEMA Standard Publication No. MG2

and local codes.

4. Motor must be securely and adequately grounded. This can be accomplished by wiring with a ground, metal-clad raceway system, using a separate

ground wire connected to the bare metal of the motor frame, or other suitable means.

5. Always disconnect power source before working on or near a motor or its connected load. Lock open position and tag to prevent unexpected application

of power.

6. In accordance with OSHA requirements, guarding is required if unit is mounted less than 7 feet above ﬂoor or where workers have access.

7. Keep hands and clothing away from moving parts.

8. Be careful when touching the exterior of an operating motor; it may be hot enough to cause injury. This condition is normal if operated at a rated load and

voltage and built to operate at higher temperatures.

9. Protect power cable from coming into contact with sharp objects.

10. Do not tangle power cable and never allow cable to come in contact with oil, grease, hot surfaces or chemicals.

11. Make sure that the power source complies to the requirements of your equipment.

Single Phase Motors

The factory assembled fan head is equipped with a 12 foot long cord and connector. To turn on fan, plug it in; to turn o fan, unplug it.

Three Phase Motors

A cord and connector is not supplied with three phase motors. These fans will need to be ﬁtted with an appropriate cord and connector or hard wired directly

to a power source. For 14”-22” fans, remove wire cover on motor and wire accordingly. For 26”-34” fans, the rear OSHA Compliant ﬁnger guard must be

removed to access the wire cover and internal wiring. Wire the fan. Replace cover and OSHA Compliant ﬁnger guard.

When looking at the front of the fan, the blade should be turning clockwise. If it does not, the electrical connection wires may need to be reversed. If reversing

the wires does not work, contact your factory representative.

OPERATING INSTRUCTIONS

803-768-3985pattersonfan.com
