There are many applications for the
Patterson Portable Stroller Fan. Use care
when selecting locations for the fan. Do not
place the fan on a sloped surface. Do not
use if the OSHA Compliant Patterson finger
guards are missing, damaged or not fitting
properly. Do not use if the cord or connector
has exposed wires or is damaged in any way.
1. Place the portable stroller on a flat
surface.
2. Secure the “U” shaped yoke to the
pedestal stroller by inserting the 5/8”
bolt through the center hole in the yoke
and through the hole in the pedestal
stroller arm. Place the 5/8” nut on the
5/8” bolt and tighten securely.
3. Carefully mount the factory assembled
fan with mounting studs through the
holes in the uprights of the “U” shaped
yoke with the motor capacitor is in up
position. Secure the fan to the yoke with
the factory supplied nuts.
Note: Due to continual product improvement,
items are subject to change without notice.
PORTABLE STROLLER
ASSEMBLY
PS
5
803-768-3985
