Problem Possible cause Solution

No sound when

power is turned on

1. The power cord is not connected 1. Connect the power cord

2. Faulty mains outlet 2. Use an outlet that receives power

3. No input source 3. Connect an input source

4. Volume set to minimum 4. Set the volume to an appropriate level

Distorted sound

1. Master volume is set too high 1. Reduce the volume

2. Damaged speaker 2. Check if the speaker is damaged

No sound from

Karaoke

1. Microphone plug is not 󰊟rmly inserted 1. Insert the mic 󰊟rmly into the socket

2. The microphone is not switched on 2. Switch the microphone on

3. Microphone volume set to the minimum 3. Increase the microphone volume

No sound from

MP3 source

1. Un supported 󰊟le format 1. Change into MP3 format

2. Illegal copy 2. Insert the USB/TF source properly

3. USB/TF source not properly inserted

Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local

authorities or your dealer about the way to proceed.

Accordance with the requirements of CE standard

Recycled products can be recycled

The product is suitable for indoor use

Speci󰈛cation

Speaker ......................................................................................................................................2 x 10"/25cm

Tweeters .................................................................................................................................................2 x 3"

Max. power ............................................................................................................................................500W

Power supply .................................................................................................................. 220-240Vac 50/60Hz

Frequency response ......................................................................................................35Hz – 20kHz (+/-5%)

S/N ratio .................................................................................................................................................. 85dB

Bluetooth frequency range ...................................................................................................2402 – 2480MHz

Max. RF emision ................................................................................................................................1.87dBm

FM band ..................................................................................................................................... 87.5-108MHz

Input sensitivity ...................................................................................................................................750mV

Input signal ............................................................................................................................................. 1kHz

Dimensions ................................................................................................................... 350 x 310 x 1000mm

Weight ..................................................................................................................................................... 17kg
