CONNECTORS ON THE REAR PANEL

MIC

USB

ON/OFF

AUX

DC5V

1 2

3 4 5 6

1. Microphone input

2. USB input

3. 5V󰐆 power input via USB C connector

4. MicroSD card input

5. AUX input

6. ON/OFF switch

CONNECTION OF A WIRED MICROPHONE (NOT INCLUDED)

Connect the microphone to the MIC socket and switch it on.

Note: If you are playing music from any other input, connecting the micro-

phone will not mute the sound output.

KARAOKE FUNCTION

This feature is available with any input. Play a track through AUX/USB/TF/Bluetooth, connect a microphone and

sing along.

USB/TF OPERATION

Keep the speaker away from high temperatures, strong magnetic 󰊟elds and any equipment that could generate

interference. If the speaker stops working, switch it o󰊞 and on again, or unplug USB/TF card and re-plug it. The

speaker should be back to normal status.

The maximum size of USB/TF device that can be connected is 32 GB.

BLUETOOTH OPERATION

1. Turn on the unit and press the input selector button on unit to select the Bluetooth function. The unit will

connect automatically to previously paired Bluetooth devices nearby.

2. For a new Bluetooth connection, activate the Bluetooth feature on the external device to be paired.

3. Initiate a search for devices. The device shows up as «PARTY-STREET».

4. Press the ▶ǁ to start playing and the buttons  and  for the selection of songs.

TWS CONNECTION

1. Power on both speakers at the same time (both speakers must have the same bluetooth name) and enter

into standby mode;

2. Long press the "mode" key on any one of the two speakers. Release when you hear a "beep". Wait about 5

seconds, and you will hear a successful connection tone.

3. Turn on the BT function of your mobile phone, search for devices and select PARTY-STREET.

4. When the two speakers are connected, long press the "mode" key of one speaker to disconnect the TWS

function.

SPECIFICATIONS

Model PARTY-STREET1 PARTY-STREET2

Speaker 4"/10cm 2 x 3"/8cm

Power 100W 100W

Frequency response 150Hz – 18kHz 150Hz – 18kHz

S/N ratio >80dB >80dB

THD <10% <10%

Rechargeable battery 3.7V󰐆 3Ah 3.7V󰐆 3Ah

BT frequency band 2402-2480MHz 2402-2480MHz

Max. RF emission power -0.32dBm -0.41dBm

Input voltage 5V󰐆 1A 5V󰐆 1A

Dimensions 310 x 145 x 170mm 335 x 150 x 190mm

Weight 1.89kg 2.1kg
