INSTALLATION

The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is 󰊟rmly 󰊟xed to

avoid vibration and slipping while operating. Always ensure that the structure to which you are attaching the

unit is secure and is able to support a weight of 10 times of the unit’s weight.

Never stand directly below the device when mounting, removing or servicing the 󰊟xture.

NAVIGATION THROUGH THE CONTROL PANEL

Access control panel functions using the four panel buttons located directly underneath the LCD Display.

Button Function

MENU Used to access the menu or to return to a previous menu option

UP Scrolls through menu options in ascending order

DOWN Scrolls through menu options in descending order

ENTER Used to select and store the current menu or option within a menu

Press MENU button to access to the 15 di󰊞erent e󰊞ects. Scroll through the e󰊞ects via the UP/DOWN buttons and

con󰊟rm the selected e󰊞ect via the ENTER button.

Factory reset: Keep the MENU button pressed for 3 seconds. The display will show DEFA which means that the

unit has been successfully reset to factory settings. All user-de󰊟ned settings have been cancelled.

EFFECT TABLE

NO. DISPLAY Function speci󰈛cation

1 d0001 DMX512 Address Code (001—512): Select an address via the UP/DOWN buttons

2 C001 Special for three channel computer system

3 A000 Colour selection (000-007): Select a colour via the UP/DOWN buttons

4 P050 Colour jump (000—255): Select the jump speed via the UP/DOWN buttons.

5 L050 Colour gradients (000—255): Adjust the gradient via the UP/DOWN buttons

6 E050 Colour pulse change (000—255): Adjust the speed via the UP/DOWN buttons

7 FLAS Adjust the speed via the UP/DOWN buttons

8 Sou1 Sound-controlled RGB colour change

9 Sou2 Sound-controlled RGBW colour change

10 FL85 Strobo󰊠ash (000—255): Adjust the 󰊠ash frequency via the UP/DOWN buttons

11 Fr85 Strobo󰊠ash (000—255): Adjust the 󰊠ash frequency via the UP/DOWN buttons

12 r255 Red colour selection (000—255): Adjust the brightness via the UP/DOWN buttons

13 g255 Green colour selection (000—255): Adjust the brightness via the UP/DOWN buttons

14 b255 Blue colour selection (000—255): Adjust the brightness via the UP/DOWN buttons

15 H255 White colour selection (000—255): Adjust the brightness via the UP/DOWN buttons

8-CHANNEL DMX CHART

CHs Value Description

CH1 0-255 RGB: Master dimmer, linear dimming from dark to bright.

CH2 0-255 R light-dimmer, linear dimming, from dark to bright.

CH3 0-255 G light-dimmer, linear dimming, from dark to bright

CH4 0-255 B light-dimmer, linear dimming, from dark to bright.

CH5 0-255 W light-dimmer, linear dimming, from dark to bright.

CH6 0-4

5-45

46-86

87-127

128-168

169-209

210-255

Constant brightness

Color Jump (P050)

Color Gradient (L050)

Color Pulse (E050)

Strobe (FLAS)

Sound control 1 Active

Sound control 2 Active

DOWN

MENU ENTER

8.8.8.8.
