Code: 15-6114PLS

PARTY-10RGB

IMPORTANT NOTE ON LITHIUM-ION BATTERIES

1. PRIOR to using the unit for the 󰊟rst time, please charge fully the battery

2. Charge the battery regularly after each use. Don’t wait until it is discharged!

3. DON’T allow the battery to discharge completely, otherwise it will lose 20% of its capacity or even be

totally damaged!

If the voltage becomes too low, the internal circuits are not powered anymore and it will become impossible

to recharge the battery!

4. If you don’t use the unit for a longer period of time, it is recommended to charge it at 40% of its capacity

and check/charge it once per month.

** BATTERIES ARE NOT COVERED BY THE WARRANTY **

We cannot be held responsible for damaged batteries further to the non-observance of these basic rules.

DESCRIPTION OF THE REAR PANEL CONTROLS (SEE PAGE 2)

1. Master volume control

2. BASS control: Adjustment of low frequencies

3. TREBLE control: Adjustment of high frequencies

4. Microphone volume control

5. Echo control for the microphone

6. Mic input

7. Switches the LED on the woofer on /off

8. When the power adaptor is connected, the indicator lamp will be lit a and the battery will charge

9. Radio antenna: when you use the FM tuner, please make sure the antenna is pointing vertically upwards to

optimize the reception.

10. AUX input via 3.5mm Jack

11. Input selector: Press this button to switch between the various inputs (AUX, USB, TF, Bluetooth, FM)

12. REC button: Press this button to record the sound of the wired or wireless mic on the USB or SD.

13. REPEAT: Press to toggle between repeating the current track or repeating all tracks.

14. In USB/TF/Bluetooth mode: press to go back to the previous track. In FM mode: press to go to the previous-

ly stored FM station.

15. Play/pause in USB/TF/Bluetooth mode. In FM mode, press and hold this button to start searching for radio

stations and store them automatically in the memory

16. In USB/TF Bluetooth mode: press to go to the next track. In FM mode: press to go to the next stored FM

station.

17. USB stick input

18. ON/OFF switch of the system

19. 9Vdc input connector

20. TF card input

21. Lights up when the LED light effect on the woofer is switched on

DESCRIPTION OF THE REMOTE CONTROL

1. MUTE: Mutes the sound output

2. Input selector: Press this button to switch between the various inputs (AUX, USB, TF,

Bluetooth, FM)

3. REC: Press to record your voice

4. REC PLAY: Press to play your record

5. Increase the volume

6. Select previous file

7. Play/Pause/Select

8. Select next file

9. Reduce the volume

10. Repeat tracks / random play

11. Equalizer: Cycles through the various music styles: Normal – Rock – Classic – Jazz –

Pop

12. Number buttons for direct input of a file number. Press the number of the file to

access it directly. For files numbers above 9, press 1+ the unit. Ex. For file number 15,

press 1 + 5. For file number 38, press 3+8

10 11

MUTE

REC

PLAY

REC

SCAN

VOL+





VOL-
