PWSAP 20-Li D4
GB
│
IE
│
11 ■
ATTENTION!
♦ If the red control LEDt flashes, this means
that the battery pack4 has overheated and
cannot be charged.
♦ If the red and green control LEDst z both
flash, this means that the battery pack4 is
defective.
♦ Switch off the charger for at least 15 minutes
between successive charging sessions. Also
disconnect the power plug from the mains
power socket.
Attaching/disconnecting the
battery pack to/from the tool
Inserting the battery pack
♦ Snap the battery pack4 into the handle.
Removing the battery pack
♦ Press the release button7 and remove the
battery pack4.
Checking the battery charge level
♦ Press the
battery charge level button 5 to
check the status of the battery (see also main
diagram).
The status/remaining charge is shown on the
battery display LED 6 as follows:
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Fitting the protective cover for cutting
When cutting with bonded abrasives, always use
the protective cover f for cutting.
♦ Slide the protective cover f onto the blade
guard s (see fig. F) until the plastic clip d
snaps into place at the end.
♦ To remove the protective cover f, pull the
plastic clip d slightly forwards to release the
protective cover f.
Adjusting the blade guard
WARNING! RISK OF INJURY!
► Always switch the tool off and remove the
battery before carrying out any work on the
tool.
RISK OF INJURY!
► Never use the angle grinder without the
blade guard s. The blade guard should be
fitted securely onto the grinder. Set it so that
the highest possible degree of safety is
achieved, i.e. the operator is exposed to the
smallest possible amount of the grinding disc.
The blade guard s is designed to protect the
operator from fragments and accidental con-
tact with the grinding tool.
► Make sure that the blade guard s is fitted
with at least the same angle as the additional
handle 8 (see fig. B). Otherwise, you could
cut injure yourself on the roughing disc or
cutting disc.
♦ Turn the blade guard s to the required position
(working position). Make sure that the blade
guard s is positioned in such a way that the
blade guard fixture e
is lying over one of the
bulges a
on the blade guard s
(see fig. E,
fold-out page).
♦ Make sure that the blade guard fixture e is
firmly seated in the respective bulge a.
Fitting the additional handle
CAUTION!
► For safety reasons, this tool may only be used
with the additional handle8 fitted. Failure to
do so can lead to serious injury. The additional
handle8 can be screwed onto the left, the
right or the top, depending on the job at
hand.
