PTHSA 20-Li C4
GB
│
IE
│
3 ■
Technical specifications
Rated voltage 20 V (DC)
Idle stroke speed 1150 rpm
Nominal stroke rate 2300 min
-1
Working angle –60° to +90°
Cutting length 410 mm
Tooth spacing 15 mm
Weight (ready for use) approx. 3.7 kg
Battery PAP 20 B3*
Type LITHIUM ION
Rated voltage 20 V
(DC)
Capacity 4 Ah/80Wh
Cells 10
High-speed battery charger PLG 20 C3*
INPUT
Rated voltage 230–240 V ∼, 50 Hz
(AC)
Rated power consumption 120 W
Fuse (internal) 3.15 A
T3.15A
OUTPUT
Rated voltage 21.5 V (DC)
Rated current 4.5 A
Charging time approx. 60 min
Protection class II /
(double insulation)
* BATTERY AND CHARGER ARE NOT SUPPLIED
Noise and vibration data
Noise measurement value determined in accord-
ance with EN62841. The A-rated noise level
of the power tool is typically:
Sound pressure level L
PA
= 71.7 dB (A)
Uncertainty K = 3 dB
Sound power level L
WA
= 84 dB (A)
Guaranteed sound
power level L
WA
= 86 dB (A)
Uncertainty K = 2.05 dB
Vibration values (vector total of three directions)
determined in accordance with EN 62841:
Vibration emission value a
h
< 2.5 m/s
2
Uncertainty K = 1.5 m/s
2
Wear ear muffs!
NOTE
► The vibration emission values and the noise
emission values given in these instructions
have been measured in accordance with a
standardised test procedure and can be used
for comparison of the power tool with another
tool.
► The specified total vibration values and the
noise emission values can also be used to
make a provisional load estimate.
WARNING!
► Depending on the manner in which the power
tool is being used, and in particular the kind
of workpiece being worked, the vibration and
noise emission values can deviate from the
values given in these instructions during actual
use of the power tool.
► Try to keep the vibration load as low as
possible. Measures to reduce the vibration
load are, e.g. wearing gloves and limiting the
working time. Wherein all states of operation
must be included (e.g. times when the power
tool is switched off and times where the power
tool is switched on but running without load).
