8 GB/IE/NI
Intended use
This product is intended for cutting grass
and weeds in the garden and for edge
trimming. Do not use the product to trim
hedges or bushes.
Any other use or modification of the product
are considered improper use and can result
in hazards such as death, life-threatening
injuries and damage. The manufacturer
is not liable for any damages caused by
improper use.
This product is designed for domestic use
and similar applications. The product is not
suitable for commercial use.
The product is designed for use by adults.
Adolescents over the age of 16 may use
the product only under supervision. The
operator or user is responsible for accidents
or damage to other people or their
property.
The product is part of the series Parkside
X 20 V TEAM. The product can be
operated using batteries from the series
Parkside
X 20 V TEAM. The batteries may
only be charged using chargers from the
series Parkside
X 20 V TEAM.
Scope of delivery
m
WARNING!
u The product and the packaging are
not children’s toys! Children must not
play with plastic bags, sheets and small
parts! There is a danger of choking and
suffocation!
1 Cordless Lawn trimmer
2 Line spools (1× already mounted)
1 Protective cover
1 Distance roller
1 Auxiliary handle
4 Phillips screws
1 Spacer bow
1 User manual
INFO: Battery and charger are not
included in the scope of delivery.
Parts list
Before reading, unfold the pages containing
the illustrations and familiarise yourself with all
functions of the product.
Figure A and B
[1] Top handle
[2] On/off switch
[3] Switch lock
[4] Receptor for spare spool
[5] Auxiliary handle
[6] Handle rod
[7] Lock of handle rod adjustment
[8] Threaded bush for length adjustment
[9] Telescopic shaft
[] Motor head
[] Push button for tilt angle adjustment
[] Protective cover
[] Spool cap
[] Line spool
[] Distance roller
[] Spacer bow (flower guard)
[] Battery*
[] Release button
[] Battery charge level indicator
[] Battery charger
Figure C
[] Phillips screw
Figure D
[] Release (spool cap)
[] Line outlet loop
[] Slot (spool)
[] Locking button (spool)
[] Line cutter
[] Opening on the spool
Figure E
[] Handle holder
[] Handle screw
* Battery and charger are not included in the
scope of delivery.
