GB / IEֺ
|
ֺ
♦ To do this, remove the dust box 3 from
the appliance as described above. Clean
the dust box 3 thoroughly by knocking
out the dust.
Reducer
Connection
♦ Push the reducer 4 into the adapter
connection 5.
♦ Push the hose of a suitable dust extrac-
tor (e.g. a workshop vacuum cleaner)
onto the reducer 4.
Removal
♦ 3XOOWKHKRVHRIWKHGXVWH[WUDFWRURƙWKH
re ducer 4.
♦ 3XOORƙWKHUHGXFHU4.
Use
&$87,21
► Ensure that the appliance is switched
RƙEHIRUHFRQQHFWLQJLWWRWKHPDLQV
NOTE
►
Always switch the multi-sander on
before applying it to the material, then
move the appliance over the workpiece.
6ZLWFKLQJRQDQGRƙ
6ZLWFKLQJWKHDSSOLDQFHRQ
♦ Move the ON/OFF switch 1 to the "I"
position.
6ZLWFKLQJWKHDSSOLDQFHRƙ
♦ Move the ON/OFF switch 1 to the "0"
position.
Speed preselection
Use the speed control 2 to set a speed
range between 1 and 6.
♦ Level 1: low speed
Level 6: high speed
The required rotational speed depends on
the material being processed and can be
determined through practical tests.
2SHUDWLQJLQVWUXFWLRQV
■ Switch the appliance on before applying
it to the workpiece.
■ Apply minimal pressure when working.
■ Work at a constant speed.
■ Change the sanding sheets regularly.
■ Never use the same sanding sheet for
VDQGLQJGLƙHUHQWPDWHULDOVHJZRRG
followed by metal). Optimum sanding
results can only be achieved by using
clean sanding sheets.
■ Clean the sanding sheet every once in a
while using a vacuum cleaner.
■ Sand hard-to-reach places with the front
or side edge of the sanding sheet on the
sanding plate.
■ Guide the sander over the workpiece
in parallel and use overlapping sanding
motions.
■ After completing the task, lift the appli-
ance from the workpiece and then
VZLWFKLWRƙ
0DLQWHQDQFHDQGFOHDQLQJ
:$51,1*
► Always remove the plug from the mains
power socket before carrying out any
work on the appliance.
The appliance is maintenance-free.
■ Always clean the appliance directly after
completion of work.
■ Use a dry cloth to clean the housing.
■ Remove any adhering sanding dust with
a brush.
■ Never use sharp objects, petrol, solvents
or cleaning agents which can damage
plastic. Do not allow any liquids to get
into the interior of the appliance.
■ Always keep the ventilation openings
free of obstructions.
