PMBA 20-Li B2
■ 8
│
GB
│
IE
Before use
Charging the battery pack (see fig. D)
CAUTION!
► Always unplug the appliance before you
remove the battery pack from or connect
the battery pack to the charger.
NOTE
► Never charge the battery pack at an ambient
temperature of below 10°C or above 40°C.
If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level
is between 50% and 80%. The storage climate
should be cool and dry and the ambient
temperature should be between 0°C and
50°C.
♦ Connect the battery pack w to the high-speed
charger i (see fig. D).
♦ Plug the mains plug into the mains power socket.
The green charge control LEDp lights up
briefly; then the red control LEDo lights up.
♦ The green control LED p indicates that the
charging process is complete and the battery
pack w is ready for use.
ATTENTION!
♦ If the red control LED o flashes, this means
that the battery packw has overheated and
cannot be charged.
♦ If the red and green control LEDs o p both
flash, this means that the battery packw is
defective.
♦ Push the battery pack w back into the appli-
ance.
♦ Switch off the charger for at least 15 minutes
between successive charging sessions. Also
disconnect the power plug from the mains
power socket.
Inserting/removing the battery pack
Attaching the battery pack:
♦ Push the battery pack w into the handle until it
clicks into place.
Removing the battery pack:
♦ Press the release button e and remove the
battery pack w.
Checking the battery charge level
♦ Press the battery charge level button 0 to
check the status of the battery (see also main
diagram or fig. D).
The status/remaining charge will be shown
on the battery display LED q as follows:
♦ RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Fitting the additional handle
♦ Screw the additional handle 9 onto the left or
right of the appliance depending on how you
work (see fig. A on the fold-out page).
Changing the saw blade
WARNING! RISK OF INJURY!
► Wear protective gloves to avoid injury.
NOTE
► You can order replacement saw blades via
our Service hotline.
♦ Release
the saw blade clamping lever 8
by
turning it clockwise
(see fig. B on the fold-out
page).
♦ Undo the two cylinder head screws r using the
hex key z
(see fig. C on the fold-out page).
♦ Flip up the protective cap t.
♦ Carefully remove the saw blade 6. Start at the
guide rollers 7 (see fig. C on the fold-out page).
♦ Remove any sawdust with a brush or
compressed air.
