8 GB/CY
The manufacturer assumes no liability for damages due to improper use.
Not intended for commercial purposes.
Description of parts
1
H-button to switch on/off horizontal line
2
LED indicator (red: levelling off, green levelling on)
3
V-button to switch on/off vertical line
4
LOCK switch
5
Battery compartment
5 a
Battery compartment cover
6
- Tripod thread (underneath)
7
Laser beam opening
8
- quick-release fixing screw (to align with tripod thread of
cross line laser)
9
Metal bracket (to adjust screw on the quick shoe)
10
Locking screw (to adjust the angle of tripod flat head to up
to 90 degree)
11
Bubble level
11a
Lever (to fix the quick shoe)
12
Long Handle
13
Locking screw (to rotate the tripod flat head up to 360 degree
horizontally)
14
Locking screw (to adjust the height of the centre column)
15
Plastic ring
16
Blocking lever (to adjust the height of the legs)
17
Legs of the tripod
18
Tripod flat head
19
Quick shoe
Scope of delivery
1 Cross line laser
1 Tripod
2 1.5 V-Batteries, Type AA
1 Set of instructions for use
Technical data
Operating voltage: 3 V
Working area at least
1)
: 10 m
Levelling accuracy: +/- 0.5 mm/m
