6
GB IE NI
5 Handle
6 Rear hand protection
7 Battery charge level indicator
8 Screw for the chain quick-
tensioning system
9 Sprocket cover
10 Mounting screw
11 Blade bar (guide rail)
12 Saw chain
13 Blade encasing
14 Rechargeable battery
14a Release button
15 Charger
16 Oil bottle
17 Chain sprocket
18 Threaded bore
19 Chain tensioner pin holder
20 Chain tensioner pin
Safety functions
3 Switch-on block
The switch-on block must be released
for switching on the device.
4 On-off switch with safety chain
brake
On releasing the On/Off switch, the
device immediately switches off.
5 Rear grip with hand guard (6)
Protects the hand against branches and
boughs in the case of springing away
by the chain.
12 Saw chain with small spring-back
helps you to catch spring-backs with
specially developed control systems.
Technical Data
Cordless Pruning Saw ..........PGHSA 12 A1
Rated input voltage .................... 12 V
Protection category.......................... IP20
Weight (without charger+
batteries) .......................... approx. 1.2 kg
Chain bar .Hangzhou Jingfeng Tools Co. Ltd
...............................................WA0142
Chain ..... Hangzhou Jingfeng Tools Co. Ltd
WA0151
Chain pitch .................................1/4“
Chain width ............................ 1.1 mm
Teeth of the sprocket chain wheel ........ 7
Length of the chain bar .. approx. 153 mm
Sawing length ............... approx. 120 mm
Acoustic pressure level
(L
pA
) ................... 78 dB(A); K
pA
= 3.0 dB
Sound power level (L
WA
)
measured .........86.02 dB(A); K
WA
= 3 dB
guaranteed ........................... 90 dB(A)
Vibration (a
h
) .........2.6 m/s
2
; K= 1.5 m/s
2
Attention! An up-to-date list of
battery compatibility can be
found at: www.lidl.de/akku
This device can be operated with
the following rechargeable batteries:
PAPK12A1, PAPK12A2, PAPK12A3,
PAPK12B1, PAPK12B2, PAPK12B3.
This type of battery may be charged with
the following chargers: PLGK12A1,
PLGK12A2, PLGK12B2.
Charging
time (h.)
PAPK12A1
PAPK12A2
PAPK12A3
PAPK12B1
PAPK12B2
PAPK12B3
PLGK12A1 1 2
PLGK12A2 1 2
PLGK12B2 0,5 1
Temperature............................max 50 °C
Charging process ...................4 - 40 °C
Operation .......................... -20 - 50 °C
Storage .................................0 - 45 °C
Noise and vibration values were deter-
mined according to the standards and
stipulations mentioned in the declaration of
conformity.
