PFBS 160 C3
GB
│
IE
│
9 ■
■ Always remove batteries from appliances that
are not in use, if possible.
■ Do attempt to recharge non-rechargeable
batteries.
There is a risk of explosion!
Original accessories/auxiliary
equipment
■ Use only the accessories and auxiliary equip-
ment that are specified in the operating instruc-
tions and are compatible with the appliance.
Operation
Changing/inserting the tool/collet
chuck
♦ Press the spindle lock and hold it down.
♦ Turn the tensioning nut
until the lock clicks
into place.
♦ Undo the tensioning nut
from the thread
using the combination spanner
.
♦ Remove any attached tool.
♦ First push the intended tool through the
tensioning nut
before inserting it into the
appropriate collet chuck
for the tool
shaft.
♦ Press the spindle lock
and hold it down.
♦ Push the collet chuck
into the thread insert
and screw the tensioning nut tight with the
combination spanner .
Using an accessory tool with a mandrel
♦ Use the screwdriver side of the combination
spanner
to undo and tighten the screw on
the mandrels or .
♦ Insert the respective mandrel
, or into
the appliance as described.
♦ Use the combination spanner
to undo the
screw on the mandrel or .
♦ Insert the desired accessory tool between the
two washers on the screw.
♦ Use the combination spanner
to tighten the
screw on the mandrel or .
Whet stone
♦ Do manually grind any edges with the whet
stone
.
Fitting abrasive belts
♦ Push the abrasive belt onto the abrasive
belt mandrel . Tighten the screw on the abra-
sive belt mandrel in order to fix the abrasive
belt
.
Fitting polishing attachments
♦ Screw the polishing attachment onto the tip
of the mandrel for polishing attachments .
Switching on and off/setting speed
range
CAUTION!
■ The rotation direction can be read off the
arrow engraved on the union nut
(anti-
clockwise symbol).
Switching on/setting the speed range
♦ Set the ON/OFF switch
to the "I" position.
♦ Set the speed control
to a position between
"1" and "MAX".
Switching off
♦ Move the ON/OFF switch
to the position
"O".
Using the grip ring with LED light
♦ Unscrew the union nut anticlockwise off the
thread.
♦ Screw the grip ring with LED
clockwise onto
the screw thread.
♦ Move the ON/OFF switch of the LED light
to
the position "I" to switch it on (see fig. C).
♦ Move the ON/OFF switch of the LED light
to
the position "O" to switch it off again.
