8 GB/IE/NI
Rated pressure:
25 bar
(2.5 MPa) max.
Working pressure: 22 bar (2.2 MPa)
Permissible water
intake pressure:
5 bar (0.5 MPa)
max.
Max. water follow
rate: 2.5 l/min
Max. water suction
height: 3 m
Degree of ingress
protection: IPX1
Water hose [9]
length: 6 m
Cleaning agent
bottle [] capacity: 500 ml
Battery pack PAP20B1 *
Model number: HG08297
Type: Lithium-Ion
Rated voltage: 20 V max.
Capacity: 2.0 Ah
Energy value: 40 Wh
Number of cells: 5
Battery pack PAP20B3 *
Model number: HG08981
Type: Lithium-Ion
Rated voltage: 20 V max.
Capacity: 4.0 Ah
Energy value: 80 Wh
Number of cells: 10
Rapid battery
charger PLG20C3 *
Model number: HG08983
(VDEplug)
HG08983-BS
(UKplug)
Input:
Rated voltage: 230–240 V
~
Rated frequency: 50 Hz
Rated power: 120 W
Fuse (internal):
3.15 A/
Output:
Rated voltage: 21.5 V
Charging current: 4.5 A
Protection class:
II/
* Battery pack and battery charger (rapid
battery charger) are not included.
m
ATTENTION!
u The recommended ambient temperature
for charging the battery is +4 to +40°C.
Charging at a temperature outside the
specified range may damage the battery
and increase the risk of fire.
Charging time:
Battery type PAP20B1, 2.0 Ah
(available separately): 45 minutes
Battery type PAP20B3, 4.0 Ah
(available separately): 60 minutes
General safety
instructions
General power tool safety
warnings
m
WARNING!
u Read all safety warnings,
instructions, illustrations and
specifications provided with
this power tool. Failure to follow
all instructions listed below may result in
electric shock, fire and/or serious injury.
