GB
│
IE
│
5 ■
PBSD900A2
5. Service
a) Have your power tool serviced by a qualified
repair person using only identical replace-
ment parts. This will ensure that the safety of
the power tool is maintained.
Appliance-specific safety instructions
for grinders
■ Hold the appliance by the insulated handles
as the abrasive belt can come into contact
with its own power cable. Damage to a live
wire may make exposed metal parts of the
power tool live and could give the operator an
electric shock.
WARNING!
■ Dusts from materials such as leaded paint,
some types of wood and metal can be
harmful to your health.
■ Contact with or inhalation of these dusts can
represent a health hazard for the person
operating the appliance and other people in
the vicinity.
■ Wear safety goggles and a protective dust
mask!
Operation
Tensioning/replacing the abrasive
belt
WARNING! RISK OF INJURY!
■ Always remove the power plug from the wall
socket before carrying out any work on the
belt grinder.
1. Loosen the clamping device for the abrasive
belt by swivelling the clamping lever
all the
way out. The abrasive belt can now be
removed.
2. Now fit a new abrasive belt or swap the
belt to work on a different material or to use
adifferent grain size.
IMPORTANT: The direction of the arrows on
the inside of the abrasive belt and on the
appliance housing must match.
3. Push the clamping lever
back into its initial
position.
Manually adjusting the abrasive belt
If the belt tracking is not centred when you switch
on the appliance, you may need to manually
adjust it.
♦ To do this, turn the adjusting screw
on the
front roller until the abrasive belt is running
centred.
IMPORTANT: It is important to ensure that
the abrasive belt does not rub against the
housing. Check the belt tracking regularly and
adjust it with the adjusting screw if required .
Adjusting the additional handle
You can position the additional handle in
several different positions.
♦ To reposition the additional handle
undo the
screw .
♦ Move the additional handle
to the required
position.
♦ Retighten the screw
.
Flipping up the front cover
You can flip up the front cover to grind in
hard-to-reach areas (see illustration).
WARNING!
► The front cover
can only be flipped
upwards if the additional handle is also
positioned upwards (see section "Adjusting
the additional handle").
♦ Flip up the front cover
.
