PBHAP 12 A1
■ 2
│
GB
│
IE
Introduction
Congratulations on the purchase of your new appli-
ance. You have chosen a high-quality product. The
operating instructions are a part of this product.
They contain important information about safety,
usage and disposal. Before using the product,
please familiarise yourself with all instructions re-
garding safety and use. Use the product only as
described and for the specified range of applica-
tions. Please also pass on all documents to any
future owner.
Intended use
The appliance is suitable for:
▯ Hammer-drilling into brickwork, concrete and
stone
▯ Chiselling into concrete, stone and plaster
▯ Drilling/screwing into stone, wood and metal
Any other usage or modification of the appliance is
deemed to be improper and carries a significant
risk of accidents.
The manufacturer accepts no responsibility for
damage attributable to misuse. The appliance is
not intended for commercial use.
Depicted components
1 Function selector switch
2 Release button for the function selector switch
3 Rotation direction switch
4 On/Off switch
5 Battery pack*
6 Battery LED
7
Release button for the battery pack
8
LED work light
9 Dust protection cap
0 Tool holder
q Locking sleeve
w Quick-release chuck
e Screwdriver bits
r
SDS drill bits
t
Wood drill bits
z Charger*
* BATTERY AND CHARGER ARE NOT SUPPLIED
Package contents
1 12 V cordless hammer drill
1
two-sleeve 10 mm quick-release chuck with
SDS shank
2
drill bits with SDS shank, 6 mm, 8 mm
2
drill bits for wood, 3 mm, 5 mm
4
50 mm screwdriver bits, SL5, PH2, PH1, T25
1 carrying case
1 set of operating instructions
Technical data
Rated voltage 12 V (DC)
Idle speed n
0
0–900 rpm
Stroke rate 0–6575 strokes per
minute
Impact energy approx. 1.1 joules
Max. drill bit diameter 10 mm for metal
13 mm for concrete
13 mm for wood
The appliance is part of the Parkside
series and can be operated using Parkside
batteries.
Batteries from the Parkside
series may
only be charged using Parkside series
chargers.
We recommend that you only operate this
appliance with the following batteries:
PAPK12A1/A2/A3/B1/B3/C1/D1/
PAPK122.5/5.0 A1.
We recommend that you charge these batteries
with the following chargers:
PLGK12A1/A2/A3/B2/PLGK 12 6.0 A1/PD-
SLG12A1.
IB_449982_PBHAP12A1_LB8.indb 2 24.05.2024 09:42:21
