22 GB/IE
Any other use or modification of the product are
considered improper use and can result in hazards
such as death, life-threatening injuries and damage.
The manufacturer is not liable for any damages
caused by improper use. The product is not intended
for commercial use or for any other use.
Scope of delivery
m
WARNING!
u The product and the packaging materials
are not children’s toys! Children must not
play with plastic bags, sheets and small
parts! There is a danger of choking and
suffocation!
1× HVLP Paint Spray Gun
4× Nozzle*:
Ø 1.5 mm
Ø 1.8 mm
Ø 2.2 mm
Ø 2.6 mm
1× Viscosity measuring cup
1× Cleaning needle
1× Cleaning brush
2× Filter**
1× Operating instructions
* 1 nozzle is pre-installed
** 1 filter is pre-installed
Parts description
Figure A:
[1] Nozzle, 4×
Ø 1.5 mm
Ø 1.8 mm
Ø 2.2 mm
Ø 2.6 mm
[2] Needle
[3] Small thread
[4] Spray unit
[5] Align spray unit
[6] Connecting tube
[7] Trigger
[8] Adjusting wheel
[9] Paint container
[] Riser tube
[] Large thread
[] Union nut
[] Nozzle head
Figure B:
[] Motor unit
[] Air filter
[] Release button
[] Air filter cover
[] Power cord with power plug
[] Spare air filter
[] Measuring cup
[] Cleaning needle
[] Cleaning brush
[] Handle
[] Lock
[] Spray connection
[] Unlocked
[] Locked
Technical data
Rated power : 450 W
Rated voltage : 230 V∼
50 Hz
Delivery rate : 950 ml/min
(water)
Paint container : 1200 ml
Max. viscosity : 70 DIN/sec
Protection class :
II/
Noise emission value
The measured values have been determined in
accordance with EN 62841. The A-rated noise level
of the power tool is typically as follows:
Sound pressure level L
pA
: 80 dB(A)
Uncertainty K
pA
: 3 dB
Sound power level
L
WA
: 91 dB(A)
Uncertainty K
WA
: 3 dB
Vibration emission value
Vibration emission values (triaxial vector sum)
determined according to EN 62841:
Vibration emission value a
h
: <2.5 m/s
2
Uncertainty
K : 1.5 m/s
2
