INSTRUCTION MANUAL
VeriSafe AVT
B21052_15 Page: 5 of 20 2-2022
Technical Specifications
Warning: Do not use this product outside of the specified performance and environmental limits. Failure
to comply with these specifications could result in product failure, personal injury, or death.
Standards
UL 1436
Standard for outlet circuit testers and similar indicating devices
CAN/CSA-C22.2 No. 160
Voltage and Polarity Testers
IEC / UL / CSA C22.2 NO. 61010-1
Safety requirements for electrical equipment for measurement, control,
and laboratory use – Part 1: General Requirements
IEC / UL / CSA C22.2 NO. 61010-2-030
Safety requirements for electrical equipment for measurement, control,
and laboratory use – Part 2-030: Particular requirements for testing and measuring circuits
UL 508 & CSA-C22.2 No. 14
Industrial control equipment
IEC 61508-1, -2, and -3 {SIL 3 Rating}
Safety of Electrical/Electronic/programmable Electronic safety-related security systems –
Part 1 General Requirements
Part 2 Requirements for Electrical / Electronic / Programmable safety related systems
Part 3 Software Requirements
FCC - CFR 47 Part 15 Subpart B
Radio frequency devices
IEC 61326-1, -3-1, -3-1: corr 1
EN 61326-1, -3-1
Electrical equipment for measurement, control and laboratory use-EMC requirements - Part 1
Part 3-1: Immunity requirements for safety-related systems and for equipment intended to
perform safety-related functions (functional safety) - General industrial applications including
corrigendum 1
EN 55011, CISPR 11
Industrial, scientific and medical equipment - Radio-frequency disturbance characteristics -
Limits and methods of measurement
IEC / EN61000-3-2
IEC / EN61000-3-3
Electromagnetic compatibility (EMC) - Part 3-2: Limits — Limits for harmonic current
emissions (equipment input current ≤ 16 A per phase)
EN 61000-6-2
Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for industrial
environments
KN 61000-6-2
KN 61000-6-4
In an industrial environment, General immunity Test Method
Preventing interference in industrial environments, Test Method
AS/NZS CISPR 11
Australian / New Zealand Standard - Industrial, scientific and medical equipment—Radio-
frequency disturbance characteristics—Limits and methods of measurement
CAN - ICES-001
Industrial, Scientific and Medical (ISM) radio frequency generators.
CE
Conformity Marking for European Economic Area
RoHS
Restriction of hazardous substances
NOTE: By design and installation guidelines the VeriSafe AVT is not impacted by the occurrence of phenomena from IEC 61000-4-16
Applications
Electrical System
For use in 1 and 3-phase AC systems
Voltage Detection Range
Up to 600V AC (50/60Hz)*, 600V DC; Rated tolerance +10%
Absence of Voltage Threshold
3 V (See the Installation Considerations section for additional information)
Overvoltage Category
III (600 V), IV (300 V)
Degree of Protection**
Indicator Module: For Flat Surface Mounting in a TYPE (UL, NEMA and CSA) 1, 12, 4, 4X,
13, IP66, or IP67 Enclosure,
Isolation Module: Open Type, IP20
* Warning: The VeriSafe AVT is designed for use in 50/60Hz electrical systems. The AVT should not be installed on sections of a circuit
where the AVT is exposed to high frequency energy such as variable frequency drives (VFD) or other circuit elements generating high frequency
energy (waveforms exhibiting high Electro-Magnetic Interference (EMI) AC or variable frequency AC power). For more information on where to
position the VeriSafe AVT in VFD applications, see the Technical Note available on Panduit.com.
**Degree of protection specified is related to the Indicator Module only. To meet the TYPE (UL, NEMA and CSA) 1, 12, 4, 4X, 13, IP66 or IP67
requirements, mount on a flat surface of an enclosure meeting the appropriate UL TYPE or NEMA rating. Verify that the seal and o-rings are
clean to ensure proper sealing.
