PANDUIT UPS INSTALLATION MANUAL
13
Section 3 – UPS, EBP and MBS Mounting
The UPS, EBP and the MBS have different mounting options. Refer to the following
section that matches the desired mounting technique desired.
Racks
Four-post rack mounting is the recommended mounting technique for all UPS, EBP and
MBS units. The mounting hardware for this technique is provided with most units. The
units may also be mounted in a two-post rack, requiring additional mounting hardware
specified in the below section. (Note: It is recommended to mount the UPS and EBP
unit near the bottom of the rack due to the physical weight of these units). The third
mounting option is tower mounting. This is not the preferred mounting technique, but
tower mounting stands are provided with most units. The 3-Phase UPS and EBP unit
should not use this mounting technique due to the physical configuration and physical
weight of the unit.
Four-Post Racks
The UPS, EBP and MBS units come with the hardware required for installation in a
standard EIA or JIS seismic rated four-post rack with square or M5 threaded mounting
holes. The rail assemblies adjust to mount in 19” racks with a front to rear distance of
460 -1000 mm (18 to 39 inches).
CAUTION
⚫
The unit is heavy. Removing the unit from its carton requires a
minimum of two people.
⚫
When installing optional EBP(s), make sure to install the EBP(s)
directly below the UPS so the wiring between the units can use
the wiring provided with the units.
Note:
Mounting rails are required for each individual unit.
Install 2U UPS Units (U01N11L, U01N11V, U01S11L, U01S11V, U01N12L, U01N12V,
U01S12L, U01S12V, U01N13V, U01S13V, U01N14L, U01S14L, U02N11L, U02N11V,
U02S11L, U02S11V, U02N12L, U02N12V, U02S12L, U02S12V, U02N14L, U02S14L,
U03N11L, U03N11V, U03S11L, U03S11V, U03N12L, U03N12V, U03S12L, U03S12V,
U03N14L, U03S14L, U03N15L, U03S15L, U05N11L, U05S11L, U06N11L, U06S11L,
U10N11L, U10S11L, U05N12L, U05S12L, U06N12L, U06S12L, U10N12L, U10S12L)
• Install the URMKIT2 rail kit:
• Install the front side of the rail kit with 3x Phillips Pan Head M5 screws (see figure
