© Panduit Corp. 2018
OPERATION MANUAL
PES400
ENGLISH
PES400: PA28981A01_01 Page: 19 of 51 4-2018
4. MACHINE SETUP FOR PRODUCING PLATES
*Easy-Mark Plus™ version 1.2 or higher, also located on the provided USB Drive, is required
to operate the PES400 Embossing System.
4.1 Quick Start Steps for Changing Plate Sizes and Embossing
□ Unlock cover with cover key and open machine cover.
□ Remove the top weight(s) [Figure 1]. (For 1.72” (43mm) wide plates, complete Step 4.2.4
on [Page 21] first.)
□ Remove any remaining plates. (For 1.72” (43mm) wide plates, complete Step 4.2.4 on
[Page 21] first.)
□ Loosen the right-hand side thumb screw and slide the right-hand side wall to open the
loader. [Figure 1 and Figure 5]
□ Change the Plate Support Block if needed, Step 4.2.4 on [Page 22] to determine correct
plate support block.
□ Adjust the Gate Height [Page 26].
□ Position Guide Rails [Page 30].
□ Load the plates [Page 32] with Easy Feed Humps up.
□ Put the top weight on [Figure 20].
□ Align the back edge of Side Eject Guide Plate [Page 32].
□ Close machine cover.
□ Adjust the insert of the external hopper to corresponding slot or use corresponding insert
[Figure 24] on [Page 34].
□ Turn on PES400 [Page 36].
□ Run Easy-Mark Plus [Page 36]. ***Version 1.2 or higher required***
□ Emboss one plate [Page 39] to review if embossing force adjustment [Page 40] is needed.
□ If any error happens, check the Error Codes on [Page 43] to debug the issue.
